The PATON PRO-270 is a compact 270A arc welder, ideal for professional and industrial welding works. This inverter welder is also capable of TIG Lift and MIG/MAG welding after the purchase of a wire feeder. The PATON PRO-270 welder has a work stabilisation system installed, allowing it to be powered by a generator. The 270A output enables the use of electrodes from 1.6mm to 6.0mm in diameter and semi-automatic welding with solid wire from 0.6mm to 1.2mm in diameter (MIG/MAG welding is possible after purchasing a wire feeder). The PRO-270 features a 70% duty cycle and a 3-year warranty.
Universal inverter welder PATON PRO-270 is designed for manual arc welding with the MMA method, argon-arc welding with the TIG method with direct current and semi-automatic welding with the MIG/MAG method in a shield of gases and protective mixtures. The PATON™ PRO-270 welder has a work stabilisation system installed, allowing it to be powered by a generator. The 270A output allows the use of electrodes from 1.6mm to 6.0mm in diameter and semi-automatic welding with solid wire from 0.6mm to 1.2mm in diameter (MIG/MAG welding is possible after purchasing a wire feeder). The PRO-270 features a 70% duty cycle and a 3-year warranty.
PATON Shoulder Strap
PATON MMA Cable Kit, 3m Electrode Lead with 3m Earth Return, 25mm²
PATON 3 Year Warranty
The PATON PRO-270 Arc Welder offers full electronic control and allows greater control of the welding process for each of the selected methods, as well as allowing maximum utilisation of the equipment's potential.
Straight answers to the questions people ask most when choosing and using a three phase arc welder.
Three phase power supplies energy more evenly and in larger amounts than a single phase supply, so three phase welders can produce higher currents and sustain them for longer. They suit heavy fabrication, structural work, workshops with frequent welding and any job using large electrodes.They also tend to draw less current per phase for a given output, which puts less strain on the supply.
Yes, normally. These machines need a three phase supply of the right voltage and capacity. Many industrial units have it but most homes and small premises do not.Some machines can be connected to a suitable three phase generator, and some multi-voltage models accept a range of supplies. Always check the data plate and manual for the voltage range, current draw and fuse rating, and have connection to the supply made by a qualified electrician.
In the UK, three phase supplies are commonly described as either 400 or 415 volts, which is essentially the same nominal supply described in different ways. Welders are designed to tolerate the normal variation in supply voltage.What matters more is that the machine is designed for the supply voltage range you have. Check the data plate, and if the machine lists a range or multiple voltages, follow the maker's instructions for configuring it.
Duty cycle is the portion of a ten minute period a welder can run at a given current. Heavy welding at high current for long periods is hard on any machine, and running past its duty cycle triggers the thermal cut-out.Choose a machine whose duty cycle at your normal working current comfortably covers the length of your welds. Machines with a higher rating at the current you use stay cooler and last longer.
