Rapid Ref : 1014020012

PATON PRO-200 Digital Inverter 200A Arc Welder Suitcase Package - 230v, 1ph
1014020012

Click here to see what's included
£345.00  EX VAT
SSP Suggested Selling Price = £430.00  YOU SAVE £85.00
 Buy in 3 easy interest free payments of £115.00† with
Additional items to consider
Select Model Required
ESAB Swarm A20 Helmet 9 - 13 x1 £55.02
Kemppi S1030 Welding Helmet 9-13 x1 £40.04
ESAB Savage A41 Welding Helmet 8-13 x1 £89.00
Select Style Required
Ultima S6 Red/Gold Premium Gauntlet x1 £5.76
Panther Pro Welding Gauntlet x1 £9.75
Spiderhand MIG Supreme MIG Welding Gloves x1 £18.75
Kemppi Craft MIG Model 6 Welding Gloves x1 £21.12
Select Welding Rods
ESAB GoldRox E6013 Electrodes 2.5mm 2.5kg x1 £19.12
ESAB GoldRox E6013 Electrodes 3.2mm 2.3kg x1 £15.72
ESAB GoldRox E6013 Electrodes 4.0mm 2.4kg x1 £16.24

The PATON PRO-200 is a compact 200A arc welder, ideal for professional and industrial welding works. This inverter welder is also capable of TIG Lift and MIG/MAG welding after the purchase of a wire feeder. The device's small size makes it very mobile. The PATON PRO-200 welder has a work stabilisation system installed, allowing it to be powered by a generator. The 200A output allows the use of electrodes from 1.6mm to 5.0mm in diameter and semi-automatic welding with solid wire from 0.6mm to 1.0mm (MIG/MAG welding is possible after purchasing a wire feeder). The PRO-200 features a 70% duty cycle and a 5-year warranty.

All machines supplied by Rapid Welding are load tested, have a gas hose with 3.8" fittings supplied and a UK plug adaptor included.

  • Powerful Output in a Compact Package: Weld with confidence — the PRO-200 delivers up to 200A of steady, reliable power for MMA (Stick) welding. For electrode diameters 1.6mm up to 5.0mm
  • Multi-Process: MMA, TIG Lift, MIG-MAG (after purchase of wire feeder)
  • Lightweight & Portable: Weighs just 5.6 kg – ideal for site work, and hard-to-reach spots
  • Ukrainian Engineering: Built by Paton™ in Europe, one of Europe’s most trusted welding brands with over 60 years of innovation
  • Generator Ready: Possibility to work on long extension cables as well as with a generator
  • Hot-Start, Arc-Force, Anti-Force, Pulse x3 functions
  • 5-Year Warranty

Product Details

Universal inverter welder PATON PRO-200 is designed for manual arc welding with the MMA method, argon-arc welding with the TIG method with direct current and semi-automatic welding with the MIG/MAG method in a shield of gases and protective mixtures. The PATON™ PRO-200 welder has a work stabilisation system installed, allowing it to be powered from a generator. The 200A output allows the use of electrodes from 1.6mm to 5.0mm in diameter and semi-automatic welding with solid wire from 0.6mm to 1.0mm (MIG/MAG welding is possible after purchasing a wire feeder). The PRO-200 features a 70% duty cycle and a 5-year warranty.

Specification

Mains Voltage: 230V
Welding Current Range: 10 - 200A
Duty Cycle: 200A at 70%, 167A at 100%
Maximum Power Consumption: 7.4kVA
Open Circuit Voltage: 12 / 75V
Dimensions (L x W x H): 330mm x 115mm x 262mm
Weight: 5.6kg
Protection Class: IP33

Perfect For

  • Professional and industrial welding works
  • Productions and installation of various metal structures
  • Pipelines welding
  • Welding in construction

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   PATON PRO User Manual

What's Included

PATON-CASE PATON Carry Case

PATON Carry Case

PATON-SSTRAP PATON Shoulder Strap

PATON Shoulder Strap
PTN-MMA16CBL PATON MMA Cable Kit, 3m Electrode Lead with 3m Earth Return, 16mm²

PATON MMA Cable Kit, 3m Electrode Lead with 3m Earth Return, 16mm²

WARRANTYP5 PATON 5 Year Warranty

PATON 5 Year Warranty

Warranty and Support

  • 5-Year Warranty
  • UK based service centre and support hotline
  • Access to spare parts and calibration service

Whether you're welding in the field, or on the job site, the PATON PRO-200 Arc Welder gives you the power, precision, and portability you need, without the bulk.

230v Arc Welders FAQs

Straight answers to the questions people ask most when choosing and using a 230 volt single phase arc welder.

Why choose a 230 volt arc welder?icon-minus-redicon-plus-red

A 230 volt single phase welder plugs into the ordinary mains supply found in most workshops, garages and homes, so there is no need for a three phase installation. Modern inverter designs draw modest current for the welding power they produce.

They suit repair work, fabrication, maintenance and light industrial use, and they are popular both with trade users and with serious hobbyists.

How do I choose the right output current?icon-minus-redicon-plus-red

Think about the thickest metal and the largest electrode you expect to use regularly, then choose a machine that provides that current comfortably within its duty cycle, not at its limit.

A machine with some spare capacity runs cooler and lasts longer. As a rough guide, small portable units handle light fabrication and repairs, and larger single phase machines cope with thicker steel and bigger electrodes, but exact limits vary between models.

What is the difference between a transformer and an inverter welder?icon-minus-redicon-plus-red

Transformer welders use a heavy iron and copper transformer to reduce the voltage. They are robust and simple, but they are heavy and usually draw more current from the supply for the same output.

Inverter welders convert the supply electronically before reducing it, which makes them noticeably lighter and smaller, and usually gives a smoother, more controllable arc. Most current 230 volt welders are inverters. The exact weight and energy saving vary from machine to machine, so compare the weight and input current on the data plate and in the manual for the machines you are considering.

Can I run a 230 volt welder from a generator?icon-minus-redicon-plus-red

Sometimes, but not every welder suits every generator. The generator must supply the welder's input current continuously, with a margin, and give a clean, stable voltage. A generator that is too small or poor quality can cause cut-outs, an unstable arc and damage to the welder's electronics.

Size the generator from the welder's input power, not its welding output, and check the welder's manual and data plate for any generator guidance. If the manual does not say the machine is suitable for generator use, ask the maker before connecting it.
