Rapid Ref : 55.04.033PKG

Bohler Uranos NX3200 GSM MIG Welder Package, 400v 3ph
55.04.033PKG

Name: Bohler Uranos NX3200 GSM MIG Welder Package, 400v 3ph
SKU: 55.04.033PKG
Price: 10705.00 GBP

£10705.00 EX VAT

Buy in 3 easy interest free payments of £3568.33^† with

Additional items to consider

Package includes; Uranos NX 3200 GSM power source, master software, WF NX SMART wire feeder, WU 2000 cooling unit, trolley, air-cooled MIG torch, water-cooled MIG torch, air-cooled TIG torch and water-cooled TIG torch.

The URANOS NX 3200 GSM is a power source which combines the high technology of digital control with great simplicity of use to give accurate high-quality welding as a result. It is capable of meeting the welding requirements of any field of application. The wealth of technological functions and solutions makes it a valued product in all application areas where accurate and high-quality welding is required.

Brochures & Manuals

BROCHURES & MANUALS

View Brochure

415v MIG Welders FAQs

Straight answers to the questions people ask most when choosing a three-phase MIG welder for workshop and production use.

What is the difference between 400v and 415v on these machines?

In practice, very little. Older documents and some machine labels refer to 415v, while the current nominal figure for a UK three-phase supply is usually given as 400v. Machines are normally designed to work within a tolerance either side of their rated input, but the allowed range depends on the maker and the model.

Check the data plate and the manual for the supply the machine accepts, compare that with the measured supply at your site, and ask a qualified electrician if you are unsure.

Do I need special wiring or a fuse rating to install one?

Yes, it needs a three-phase connection with the correct cable size and protection for the machine's input current, installed by a competent electrician. The manual states the recommended supply cable and fuse or breaker rating.

Do not connect a machine to a circuit that has not been checked for the load. Poor supply causes tripping, overheating and unreliable welding.

Air-cooled or water-cooled: which should I choose?

Air-cooled torches are simpler and need no extra equipment, and suit many general jobs. Water-cooled torches carry higher current for longer without overheating, so they suit heavy, continuous or production welding, but they need a cooler and a little more upkeep.

Choose according to the current and the duty cycle you will use.

What is the difference between a compact and a separate wire-feeder system?

A compact machine has the wire feeder built into the power source and is simpler and easier to move. A separate (split) system has an independent wire feeder connected by an interconnecting cable, which you can carry to the work, away from the power source.

Separate feeders suit large fabrications and reaching big workpieces, and compact units suit general workshop use.

See all 6 questions for this category
