TX223GVD134 Kemppi Flexlite TX K3 223GV D13 Air Cooled 220 Amp Scratch Start TIG Torch, with 70° Angle Neck & Gas Valve - 4m
  • TX223GVD134 Kemppi Flexlite TX K3 223GV D13 Air Cooled 220 Amp Scratch Start TIG Torch, with 70° Angle Neck & Gas Valve - 4m
  • TX223GVD134 Kemppi Flexlite TX K3 223GV D13 Air Cooled 220 Amp Scratch Start TIG Torch, with 70° Angle Neck & Gas Valve - 4m
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : TX223GVD134

Kemppi Flexlite TX K3 223GV D13 Air Cooled 220 Amp Scratch Start TIG Torch, with 70° Angle Neck & Gas Valve - 4m
TX223GVD134

£159.80  EX VAT
SSP Suggested Selling Price = £177.55  YOU SAVE £17.75
 Buy in 3 easy interest free payments of £53.27† with
Shop Parts

EVERYDAY WELDING COMFORT

Kemppi presents the latest in their TIG torch range; the Flexlite TX series. These TIG torches are designed for the best reliable welding performances with a focus on the process of everyday welding. All Flexlite TX products feature tremendous technical performance lifespans and there is plenty of different sizes and types to choose from to fit your welding needs. Flexlite TX welding torches provide excellent user comfort and lower the chance of welder fatigue. A firm grip is made from silicone rubber and the torches’ innovative design reduces time in wrist loading, allowing more time to concentrate on welding tasks.

All Flexlite TX welding torches comply with standard IEC 60974-7.

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   Kemppi Flexlite TIG Torches Operator's Manual

Related Items

TIG Torch FAQs

Straight answers to the questions people ask most when choosing and looking after a TIG torch.

Do I need an air-cooled or a water-cooled TIG torch?icon-minus-redicon-plus-red

Air-cooled (also called gas-cooled) torches are lighter, simpler and cheaper, because the shielding gas flowing through them does the cooling. They suit lower currents and shorter welds. Water-cooled torches have a coolant circuit and stay cooler at higher currents, so they are the choice for thicker material and long, continuous welding, but they need a water cooler and extra hoses.

If you mostly weld thin to medium material in short runs, air-cooled is normally enough.

What do numbers like 9, 17 and 26 on a TIG torch mean?icon-minus-redicon-plus-red

Many TIG torches follow standard series designations, with numbers such as 9, 17 or 26. They show the size of the torch body, and so roughly how much current it can carry and which consumables fit it, although the number itself is not an amp rating.

The real current rating also depends on whether the torch is air- or water-cooled and on how long you weld without a break. Check the maker's rating and choose a torch above the current you will weld at.

Which tungsten electrode should I use?icon-minus-redicon-plus-red

For most work on steel and stainless steel with DC, a ceriated or lanthanated tungsten is a good all-round choice: it starts easily, lasts well and holds its shape. For aluminium with AC, zirconiated or pure tungsten is the traditional choice because it forms a small rounded tip, although many modern machines also work well with other types.

The colour band on the electrode shows its type, but colour codes differ between makers, so check the packaging. Thoriated tungsten is still seen, but it is mildly radioactive, which is why many welders now choose other types.

What is a gas lens and is it worth having?icon-minus-redicon-plus-red

A gas lens is a fine mesh in the torch that smooths the shielding gas so it leaves the cup as a steady column rather than a turbulent stream. That gives better protection, so you can often use less gas, and it lets the tungsten stick out further for a better view and for reaching into awkward joints.

It is a worthwhile upgrade for stainless steel, aluminium and any joint where you need extra reach.
