MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
  • MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
  • MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
  • MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
  • MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
  • MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
  • MSS305GM Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : MSS305GM

Kemppi Master S 305 G Arc Welder - Generator Friendly, 230/400V 3ph Multi Voltage
MSS305GM

£3393.00  EX VAT
SSP Suggested Selling Price = £3990.80  YOU SAVE £597.80
 Buy in 3 easy interest free payments of £1131.00† with
Additional items to consider
Select Model Required
ESAB Swarm A20 Helmet 9 - 13 x1 £55.02
Kemppi S1030 Welding Helmet 9-13 x1 £40.04
ESAB Savage A41 Welding Helmet 8-13 x1 £89.00
Select Style Required
4 Pin 400V 16A Mains Plug (Red) x1 £12.10
4 Pin 400V 32A Mains Plug (Red) x1 £18.32
5 Pin 400V 32A Mains Plug (Red) x1 £7.50
Select Welding Rods
Bohler Q E 6013 RC Electrodes 2.5mm 5kg x1 £30.80
Bohler Q E 6013 RC Electrodes 3.2mm 5kg x1 £28.56
Bohler Q E 6013 RC Electrodes 4.0mm 5kg x1 £28.56
EXTRA TO THE ORDINARY – OPTIMAL STICK WELDING PERFORMANCE

Master S 305 is a stylish and practical stick welding machine, capable of absorbing the knocks and impacts of everyday welding life. Premium-class stick welding is characterised by reliable ignition, arc stability, and suitability for all electrodes, including cellulosic.

Lightweight and compact, the Master S 305 is constructed from tough injection-moulded plastic, featuring impact bridge protection structures, making it your reliable partner for workshop or site use.

Master S 305 guarantees optimal welding performance and fast parameter setting, supported by the innovative Weld Assist menu selection tool. Weld Assist ensures the right parameters for each application, no matter your welding experience. Select the electrode type, electrode size, and joint type, and Weld Assist makes the perfect setting for you.

Stick welding may be a basic welding process, but Master S 305 adds the extra to the ordinary in a perfect blend for professional welding.

Product Details

FEATURES

- 60% faster parameter setting with the Weld Assist selection tool
- Wireless remote control extends usability and removes safety trip hazards
- A full-colour 7-inch TFT display ensures the best user experience
- Suitable for all electrode types
- Special welding program for cellulosic electrode welding
- 99 memory channels for saving welding parameters or WPS values
- When connected to a Flexlite TX223GVD134 TIG torch, Master S 305 provides an excellent power source for quality DC TIG welding
- Made from strong and recyclable plastics, protecting the power source from everyday knocks
- Separate models for generator use, multi-voltage applications, and VRD
- The power source is easy to combine with the optional Kemppi transport units

Related Items

230v Arc Welders FAQs

Straight answers to the questions people ask most when choosing and using a 230 volt single phase arc welder.

Why choose a 230 volt arc welder?icon-minus-redicon-plus-red

A 230 volt single phase welder plugs into the ordinary mains supply found in most workshops, garages and homes, so there is no need for a three phase installation. Modern inverter designs draw modest current for the welding power they produce.

They suit repair work, fabrication, maintenance and light industrial use, and they are popular both with trade users and with serious hobbyists.

How much welding current can a 230 volt supply provide?icon-minus-redicon-plus-red

Single phase supplies limit how much current a welder can draw, so the top-end output of 230 volt machines is lower than three phase equipment. Within that limit, a good inverter can handle a wide range of electrode sizes, from fine work to fairly heavy repair welding.

For heavy plate, long continuous welding or large diameter electrodes, a three phase machine is the better fit. Check the maker's output and duty cycle figures at the current you actually plan to use.

Does the plug and fuse on my supply matter?icon-minus-redicon-plus-red

Yes. The welder draws more current at its maximum setting than a typical household appliance. Check its input current on the data plate and make sure the plug, socket, cable and circuit protection are rated for it.

A socket circuit that is too small will trip, overheat or give a weak arc. Some machines are supplied with a particular plug rating. Have a qualified electrician check or upgrade the supply if you are unsure.

What is the difference between a transformer and an inverter welder?icon-minus-redicon-plus-red

Transformer welders use a heavy iron and copper transformer to reduce the voltage. They are robust and simple, but they are heavy and usually draw more current from the supply for the same output.

Inverter welders convert the supply electronically before reducing it, which makes them noticeably lighter and smaller, and usually gives a smoother, more controllable arc. Most current 230 volt welders are inverters. The exact weight and energy saving vary from machine to machine, so compare the weight and input current on the data plate and in the manual for the machines you are considering.

See all 6 questions for this category
