MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
  • MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
  • MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
  • MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
  • MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
  • MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
  • MSS305G Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : MSS305G

Kemppi Master S 305 G Arc Welder - Generator Friendly, 400V 3ph
MSS305G

£3280.00  EX VAT
SSP Suggested Selling Price = £3857.92  YOU SAVE £577.92
 Buy in 3 easy interest free payments of £1093.33† with
Additional items to consider
Select Model Required
ESAB Swarm A20 Helmet 9 - 13 x1 £55.02
Kemppi S1030 Welding Helmet 9-13 x1 £40.04
ESAB Savage A41 Welding Helmet 8-13 x1 £89.00
Select Style Required
4 Pin 400V 16A Mains Plug (Red) x1 £12.10
4 Pin 400V 32A Mains Plug (Red) x1 £18.32
5 Pin 400V 32A Mains Plug (Red) x1 £7.50
Select Welding Rods
Bohler Q E 6013 RC Electrodes 2.5mm 5kg x1 £30.80
Bohler Q E 6013 RC Electrodes 3.2mm 5kg x1 £28.56
Bohler Q E 6013 RC Electrodes 4.0mm 5kg x1 £28.56
EXTRA TO THE ORDINARY – OPTIMAL STICK WELDING PERFORMANCE

Master S 305 is a stylish and practical stick welding machine, capable of absorbing the knocks and impacts of everyday welding life. Premium-class stick welding is characterised by reliable ignition, arc stability, and suitability for all electrodes, including cellulosic.

Lightweight and compact, the Master S 305 is constructed from tough injection-moulded plastic, featuring impact bridge protection structures, making it your reliable partner for workshop or site use.

Master S 305 guarantees optimal welding performance and fast parameter setting, supported by the innovative Weld Assist menu selection tool. Weld Assist ensures the right parameters for each application, no matter your welding experience. Select the electrode type, electrode size, and joint type, and Weld Assist makes the perfect setting for you.

Stick welding may be a basic welding process, but Master S 305 adds the extra to the ordinary in a perfect blend for professional welding.

Product Details

FEATURES

- 60% faster parameter setting with the Weld Assist selection tool
- Wireless remote control extends usability and removes safety trip hazards
- A full-colour 7-inch TFT display ensures the best user experience
- Suitable for all electrode types
- Special welding program for cellulosic electrode welding
- 99 memory channels for saving welding parameters or WPS values
- When connected to a Flexlite TX223GVD134 TIG torch, Master S 305 provides an excellent power source for quality DC TIG welding
- Made from strong and recyclable plastics, protecting the power source from everyday knocks
- Separate models for generator use, multi-voltage applications, and VRD
- The power source is easy to combine with the optional Kemppi transport units

Related Items

415v Arc Welders FAQs

Straight answers to the questions people ask most when choosing and using a three phase arc welder.

How do I check my three phase supply is suitable?icon-minus-redicon-plus-red

Look at the welder's input current and recommended fuse or breaker rating on the data plate, then check that your supply, cable and protection can provide it. Your electrician can confirm the spare capacity of the supply and the correct plug or isolator.

A supply that is too weak causes voltage dips, nuisance tripping and an unstable arc, and cable that is too small can overheat. Do not change the rating of protective devices to get around a problem.

What is the difference between 400 volt and 415 volt on a welder?icon-minus-redicon-plus-red

In the UK, three phase supplies are commonly described as either 400 or 415 volts, which is essentially the same nominal supply described in different ways. Welders are designed to tolerate the normal variation in supply voltage.

What matters more is that the machine is designed for the supply voltage range you have. Check the data plate, and if the machine lists a range or multiple voltages, follow the maker's instructions for configuring it.

Is a three phase welder better for thick material?icon-minus-redicon-plus-red

Generally yes. Higher usable current and a stronger duty cycle mean three phase machines cope better with thick plate, large electrodes and long welding runs without overheating.

That said, a lot depends on the individual machine. Compare the output current and duty cycle at the settings you will use, rather than assuming any three phase machine will suit every heavy job.

Why does the duty cycle matter more on heavy work?icon-minus-redicon-plus-red

Duty cycle is the portion of a ten minute period a welder can run at a given current. Heavy welding at high current for long periods is hard on any machine, and running past its duty cycle triggers the thermal cut-out.

Choose a machine whose duty cycle at your normal working current comfortably covers the length of your welds. Machines with a higher rating at the current you use stay cooler and last longer.

See all 6 questions for this category
