    Rapid Ref : K14436-1

    Lincoln Sprinter 160S DC Stick & Lift TIG Inverter Dual Voltage Arc Welder - 110/230v
    K14436-1

    £420.00  EX VAT
    SSP Suggested Selling Price = £524.67  YOU SAVE £104.67
     Buy in 3 easy interest free payments of £140.00† with
    Additional items to consider

    This machine is more than just a stick welder, the Sprinter S combines superior stick functionality with DC LIFT TIG mode and dual input voltage (120V/230V). A simple display allows you to select welding settings quickly, with the ability to start any job anywhere, whether it’s maintenance work, light fabrication, light construction and everything in between.

    • DUAL INPUT VOLTAGE – 120V and 230V, enabling you to plug into any common power supply.
    • READY TO USE VERSION – Available also as a Pack version with durable suitcase and telescopic arm, power source, welding cables, welding gloves and small pack of electrodes.
    • HOT START – This is a temporary increase in the initial welding current, to helping ignite the arc quickly and reliably.
    • ARC FORCE - Helps to increase penetration and prevent electrodes from sticking.
    • MULTI-PROCESS CAPABLE – Welds DC stick and DC Lift TIG.
    • LIGHTWEIGHT PORTABILITY – Weighing under 9 kg this durable machine is easy to carry with either the ergonomic handle or shoulder strap.
    • TWO STICK MODES – Dedicated E6010 and E7108 weld modes allow for greater welding versatility and superior performance.
    • PFC – Resistant to power fluctuations, even while working on long extension cables up to 100m, without effecting welding capability and quality.

    Product Details

    Specification

    Input power  120/230v 1ph/50 Hz +/- 15%
    Rated output current/duty cycle (230Vac - MMA) 160A @ 45%
    Output range (230Vac) - TIG  10-180A DC
    Output range (230Vac) - MMA 20-160A DC
    Fuse size (A) 16
    Open circuit voltage (OCV) Average OCV - 69V
    Peak OCV - 95V
    VRD OCV (Peak) - 14V
    Dimensions HxWxD (mm) 162 x 305 x 438
    Protection / insulation class IP23S/H
    Net weight (kg) 8.40

    Related Items

    110v Arc Welders FAQs

    Straight answers to the questions people ask most when choosing and using a 110 volt arc welder.

    Why are 110 volt arc welders used on sites?icon-minus-redicon-plus-red

    On many construction and industrial sites, portable electrical equipment is required to run from a reduced 110 volt supply, because it lowers the risk of a serious shock if a cable or tool is damaged. A welder that runs from 110 volts can be connected to the site supply or to a suitable generator.

    Check your site rules, because requirements vary, and follow the instructions of the person in charge of site electrical safety.

    What is a dual voltage welder and how does it work?icon-minus-redicon-plus-red

    A dual voltage or multi-voltage welder detects or is set to accept either a 110 volt or a 230 volt supply, so one machine works on site and in the workshop. Many are inverters that adjust internally.

    The welding current you can use is normally lower on the lower voltage, so read the data plate and manual for the output at each input. Always use the correct plug and supply for the voltage in use, and never try to fit a different plug that does not match the supply rating.

    What size electrodes can I use on a 110 volt welder?icon-minus-redicon-plus-red

    This depends on the machine's output when run on 110 volts. Smaller electrodes need less current and suit these welders best, and thicker electrodes need more current than a 110 volt machine may be able to provide.

    Check the maker's guidance for the electrode sizes the machine can run at its 110 volt output. If you try to use an electrode that needs more current than the machine can supply, the arc becomes weak, difficult to strike and prone to sticking.

    What supply and plug does a 110 volt arc welder need?icon-minus-redicon-plus-red

    Site 110 volt equipment normally uses a yellow industrial plug and socket, usually at a particular current rating. The supply must be able to provide the current the welder draws, and the plug and cable must be rated for it.

    A welder drawing more current than the supply or plug is rated for will trip protective devices or overheat the cable. Check the current draw on the welder's data plate and make sure the supply, transformer or generator can provide it.
