The MasterTIG-200 AC/DC industrial inverter welding machine is designed for welding with constant, alternating, pulse, and pulse-constant currents on a wide range of materials: aluminium, aluminium alloys, steel, non-ferrous metals, and copper alloys (mainly in TIG mode). The machine can also operate in spot welding mode (SPOT) and with coated electrodes (MMA mode). The MasterTIG-200 features a 40% (DC) and 50% (AC) duty cycle, as well as a 3-year warranty.
In CLEAN mode, the machine cleans stainless-steel welding parts and their seams of oxides and discolouration, and polishes stainless-steel products. To operate in CLEAN mode, a special electrolytic solution for passivating high-alloy steels must be purchased separately. Without it, cleaning and polishing stainless steel using this function is not possible.
Specification
| Mains Voltage: |
230V |
| Welding Current Range: |
5 - 200A |
| Duty Cycle: |
DC – 40%, AC – 50%
|
| Nominal Power Consumption: |
6.3kVA
|
| Dimensions (L x W x H): |
465mm x 150mm x 350mm
|
| Weight: |
12.5kg
|
| Protection Class: |
IP23 |
Perfect For
- Automotive & Aerospace
- Pipework
- General Fabrication
