088587 Hypertherm Powermax 45 SYNC CE/CCC Machine System with 7.6m (25ft) Torch, 230v 1ph
  • 088587 Hypertherm Powermax 45 SYNC CE/CCC Machine System with 7.6m (25ft) Torch, 230v 1ph
  • 088587 Hypertherm Powermax 45 SYNC CE/CCC Machine System with 7.6m (25ft) Torch, 230v 1ph
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : 088587

Hypertherm Powermax 45 SYNC CE/CCC Machine System with 7.6m (25ft) Torch, 230v 1ph
088587

Click here to see what's included
£2293.00  EX VAT
SSP Suggested Selling Price = £3275.00  YOU SAVE £982.00
 Buy in 3 easy interest free payments of £764.33† with
Shop Parts

The world's best-selling plasma system just got better. For metal workers who want the most versatile system available to gouge, cut, and mark, Powermax  45 SYNC delivers the best return on investment. Part of the Hypertherm® Powermax® family, Powermax 45 SYNC features built-in intelligence, a patented single-piece cartridge, and up to five times longer consumable life and greater cutting power than higher-amperage competitors.

Product Details

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   Hypertherm Powermax45 SYNC Operator Manual

Related Items

All Hypertherm Machine Systems FAQs

Straight answers to the questions people ask most when choosing a plasma cutting system for mechanised and automated use.

What is a machine plasma system and what is it for?icon-minus-redicon-plus-red

A machine system uses a straight, mechanised torch mounted on a cutting table, a motion carriage, a bevel head or a robot, instead of being held in the hand. It is used for repeatable, accurate cutting of shapes and profiles from sheet and plate.

On smaller systems the power source is the same kind of air plasma unit as a hand system, while larger high-definition systems use other gases such as oxygen. The torch, the interfaces and the way it is controlled are set up for automation. Many machine systems also come with a hand torch for occasional manual work.

What interface does the plasma system need to talk to my CNC controller?icon-minus-redicon-plus-red

Machine plasma systems normally have an interface for the cutting table controller, so that the controller can start the arc and receive signals back such as arc transfer. Some systems provide extra options, such as a digital or serial link for control and diagnostics, or an arc voltage signal for a torch height controller. What is provided, and the cables and connectors needed, vary from one system to another.

Check what your controller and height control require, and compare it with the interface described in the manual for the system you are considering. If you are unsure, our team can help you match the pieces.

Which torch length should I choose for a machine system?icon-minus-redicon-plus-red

The torch lead needs to be long enough to reach the whole travel of the gantry or carriage without being stretched, snagged or pulled tight. A lead that is too short limits movement and wears quickly, while a very long one adds clutter.

Choose according to the table size and the position of the power source. Allow for a drag chain or support where the torch moves a long way.

Can I use a machine torch by hand?icon-minus-redicon-plus-red

A machine torch is designed to be mounted on a cutting table, carriage or robot, not held in the hand. It usually has no handle or trigger designed for hand use, and holding one close to the arc can leave you exposed to light, sparks and hot metal.

If you also need to cut by hand, choose a system that comes with a hand torch, or a separate hand torch intended for the purpose, and follow the maker's instructions for your own system. Never modify a machine torch for hand use.

See all 6 questions for this category
