Rapid Ref : 7-521X

Thermal Dynamics SL100 Machine 1Torch, w/ ATC Connector
7-521X

Name: Thermal Dynamics SL100 Machine 1Torch, w/ ATC Connector
SKU: 7-521X

Select Option

Prices From £845.40 ex VAT

Shop Parts

The Only Universal Plasma Torch!

As a replacement (RPT®) torch, the Torch has the ability to work on the majority of plasma power supplies on the market today. It’s unique design allows the Torch the ability to work with high frequency, touch, CD, and moving parts (blow back) start systems. 1 Year Warranty.

Ergonomic Torch Handle - Hand Torches offers ergonomic handle with easy-to-use trigger release that provides comfort during prolonged use. 75° and 90° heads offer operators a choice of positions.

New Phenolic Position Tube - With a new, innovative, easy-to-remove 32 pitch gear rack, the phenolic positioning tube can easily be adapted to any 3/8 torch holder. If manual torch position is required, the use of the gear rack will complete the task. Simply remove the gear rack from the positioning tube if not needed.

Extended or Protected Consumable Parts - We designed our consumable parts to adapt to your cutting style. By simply changing the shield cup, you can either have:

An extended tip for greater visibility and control and precision drag cutting at low power.
A protected tip for on the plate drag cutting at high power up to 20 Amps.

Lower Consumable Parts Inventories and Costs - Only 34 consumable parts cover the full range of cutting and gouging up to 20 Amps. Inventorying parts for a fleet of plasma units can be by simplified using the Torch.

Improved Leads - Torch leads are lightweight, extremely flexible, and rugged enough to withstand years of use.

Brochures & Manuals

BROCHURES & MANUALS

View Brochure

Thermal Dynamics Torches FAQs

Practical answers on choosing, using and looking after a replacement plasma torch and lead.

What is the difference between rated cut and severance cut when choosing a torch?

Cutting capacity is usually quoted in two ways. The rated, or clean, cut is the thickness the equipment can cut at a reasonable speed with a good edge. The severance cut is the absolute maximum it can part, at a slow speed and with a rougher edge.

Size your equipment so the clean-cut rating covers the metal you cut most often, and treat severance as an occasional capability. Working near the limit also tends to wear consumables much faster. The figures depend on the maker, the material and the settings, so use the specification for your own equipment.

What eye protection do I need for plasma cutting?

The plasma arc gives off intense light that can injure your eyes and burn exposed skin. Manufacturers' manuals call for eye protection with the correct filter shade for the cutting current, such as a welding-type helmet or a face shield with goggles and side shields underneath.

The right shade depends on the current you are cutting at, so use the table in your cutter's manual or the shade recommended by your risk assessment. Wear flame-resistant clothing and gloves too, and screen the area so others are not exposed to the arc.

How do I pierce plate without damaging the nozzle?

Piercing throws molten metal back up towards the torch, so the usual advice is to pierce higher and cut low: start the pierce at a greater height than the cutting height, then drop to the cut height once the arc has gone through. On a machine, the height control normally does this for you.

On thicker plate, start from the edge where you can, because piercing thick plate is hard on consumables. When you do pierce by hand, keep the spray directed away from you and the torch, and wear full protective gear. Use the heights and pierce limits in your torch's cut chart.

Why do my consumables wear faster on rusty, painted or perforated metal?

Dirty, rusty or painted surfaces make it hard for the main arc to transfer cleanly, and expanded metal or grating keeps interrupting the arc path. Each time the arc is lost, the torch has to restart the pilot arc, and the pilot arc is responsible for a large share of consumable wear.

Where you can, grind a clean contact point for the work clamp, avoid long pilot arc times, and expect to change consumables more often on this kind of work. Replace them before cut quality drops off badly.

See all 6 questions for this category
