Miller’s own MigMatic 260i synergic MIG/MAG systems feature heavy-duty drive mechanisms capable of consistent and precise wire feeding regardless of the welder’s choice of wire. These machines are quick to set up and the graphical user interface makes it easy to achieve those perfect weld parameters with limited training required. The MigMatic 260i is the perfect workshop machine and is ideal for both solid and flux core wires.
Machine supplied with 3m mains cable, and 1.0 - 1.2mm V Groove Drive Rolls
Features
<split>
Specifications
Input power: 400 V, 3 phase, 50/60 Hz
Welding output: 260 A, 27 V @ 35% duty cycle
Max. output amperage: 285 A
Output range: 15 A – 260 A
Net weight: 57Kg
Miller User Manual
Miller True Blue 3 Year Parts and Labour Warranty
Straight answers to the questions people ask most when choosing a three-phase MIG welder for workshop and production use.
Three-phase machines suit fabrication shops, production lines, engineering workshops and anyone welding thicker material or for long periods. A three-phase supply carries more power for a given current per phase, so these machines can give higher output with a steadier load on the supply.If you only have a single-phase supply, you are limited to single-phase machines.
In practice, very little. Older documents and some machine labels refer to 415v, while the current nominal figure for a UK three-phase supply is usually given as 400v. Machines are normally designed to work within a tolerance either side of their rated input, but the allowed range depends on the maker and the model.Check the data plate and the manual for the supply the machine accepts, compare that with the measured supply at your site, and ask a qualified electrician if you are unsure.
Yes, it needs a three-phase connection with the correct cable size and protection for the machine's input current, installed by a competent electrician. The manual states the recommended supply cable and fuse or breaker rating.Do not connect a machine to a circuit that has not been checked for the load. Poor supply causes tripping, overheating and unreliable welding.
Air-cooled torches are simpler and need no extra equipment, and suit many general jobs. Water-cooled torches carry higher current for longer without overheating, so they suit heavy, continuous or production welding, but they need a cooler and a little more upkeep.Choose according to the current and the duty cycle you will use.
