Miller Dynasty 400 AC/DC TIG Welder, 380-575v
Miller-DYNASTY400

Name: Miller Dynasty 400 AC/DC TIG Welder, 380-575v
SKU: Miller-DYNASTY400

Select Option

Prices From £6364.00 ex VAT

Reimagined for Your Pursuit of Perfection. Experience unfailing precision arc performance paired with a state-of-the-art, user-friendly interface that puts advanced capabilities at your fingertips.

Features

Portable in the shop or at the jobsite—at 6.0 kg (13.2 lb.) The shoulder strap allows the end user to move from location to location easily.
Simple-to-use operator interface, inverter-based, DC power source has a simple-to-use operator interface providing only the necessary controls in a compact machine.
Dual fan technology optimised power source cooling system which enables the machine to operate at a lower temperature, thus increasing its performance and life cycle.
Thermal overload protection with an indicator light helps prevent machine damage if the duty cycle is exceeded or airflow is blocked.
VRD function is a simple design that reduces the open-circuit voltage to 20 volts when the welding power source is not in use.

Brochures & Manuals

BROCHURES & MANUALS

View Brochure

Miller Dynasty 400, 800 / Maxstar 400 CE & Non-CE Owner's Manual

415v TIG Welders FAQs

Straight answers to the questions people ask most when choosing and using three phase TIG welders.

Why choose a three phase TIG welder?

Three phase machines are designed for industrial use, where a three phase supply is installed. The supply can provide far more power than a single phase socket, so these machines provide higher welding currents, heavier duty cycles and the ability to weld thick sections, especially aluminium, all day.

They are the usual choice for fabrication shops, pipe welding, heavy repair and production work, where reliability and capacity matter more than portability.

Can I run a three phase TIG welder from a generator?

Sometimes, but only if the generator is a three phase unit suited to the welder. Check the data plate and manual for your machine for its input current and any minimum generator size or type the maker states.

Generators are rated for balanced three phase loads, and power factor affects the size you need, so allow a generous margin above the welder's input requirement. The output must be stable and well regulated. An undersized or poor quality generator can cause cutting out, an unstable arc or damage to the electronics. If in doubt, ask the maker or a competent electrician before connecting.

How do I choose the output rating?

Consider the thickest material and the metal. Aluminium needs more current than steel for the same thickness. Choose a machine with a maximum current comfortably above what you will need regularly, since this gives a better duty cycle, a cooler running machine and headroom for heavier jobs.

Also consider the lowest current. A machine with a low, stable minimum current suits thin material and precise work. A wide range between minimum and maximum makes the machine more versatile.

AC/DC or DC only: which do I need?

A DC machine welds steel, stainless steel, copper and many other metals, but not aluminium or magnesium. An AC/DC machine adds AC output, which cleans the oxide layer on aluminium and magnesium so they can be welded properly.

If you will ever weld aluminium, choose AC/DC. Look for adjustable AC balance and frequency, which let you tune the cleaning action and the arc focus.

See all 6 questions for this category
