K14242-1P Lincoln Invertec 275S Stick & Lift TIG Inverter Arc Welder Ready to Weld Package - 400v, 3ph
  • K14242-1P Lincoln Invertec 275S Stick & Lift TIG Inverter Arc Welder Ready to Weld Package - 400v, 3ph
  • K14242-1P Lincoln Invertec 275S Stick & Lift TIG Inverter Arc Welder Ready to Weld Package - 400v, 3ph
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : K14242-1P  Mfr Ref : K14242-1

Lincoln Invertec 275S Stick & Lift TIG Inverter Arc Welder Ready to Weld Package - 400v, 3ph
K14242-1 K14242-1P

Click here to see what's included
£1976.00  EX VAT
SSP Suggested Selling Price = £2469.52  YOU SAVE £493.52
 Buy in 3 easy interest free payments of £658.67† with
Additional items to consider
Select Model Required
ESAB Swarm A20 Helmet 9 - 13 x1 £55.02
Kemppi S1030 Welding Helmet 9-13 x1 £40.04
ESAB Savage A41 Welding Helmet 8-13 x1 £89.00
Select Style Required
4 Pin 400V 16A Mains Plug (Red) x1 £12.10
4 Pin 400V 32A Mains Plug (Red) x1 £18.32
5 Pin 400V 32A Mains Plug (Red) x1 £7.50
Select Welding Rods
Bohler Q E 6013 RC Electrodes 2.5mm 5kg x1 £30.80
Bohler Q E 6013 RC Electrodes 3.2mm 5kg x1 £28.56
Bohler Q E 6013 RC Electrodes 4.0mm 5kg x1 £28.56

The new Invertec 275S is a next-generation STICK inverter that offers excellent welding processes coupled with high performance and increased productivity and is the next step in professional welding. Due to its unique design, the new Invertec 275S is designed with the latest energy-saving technology and is ready to work in the most difficult environments.

To achieve excellent welding results, the Invertec 275S comes complete with in-built communication devices and digital transmission systems, such as USBs, allowing the operator to monitor and track welding operations more easily.

Features

  • High production efficiency
  • Digital welding current control
  • True HD tested – made to withstand harsh environmental conditions
  • Low power consumption due to high-efficiency energy cost saving
  • Automatic power-saving modes (standby/shut-down function)
  • Operators can perform self-calibration
  • Generator ready
  • Protection class IP23
  • 3-year full parts and labour warranty

Product Details

Specification

  • Input power: 9.7 kW (11 kVA)
  • Rated output: 270A@25% / 250A@35% / 230A@60% / 180A@100%
  • Welding current range: 5 - 270 A
  • Dimensions: 36 x 23 x 50cm
  • Weight: 14.3Kg

What's Included

K14242-1 Lincoln Invertec 275S MMA Power Source 3ph

Lincoln Invertec 275S MMA Power Source 3ph

LMANUAL Lincoln Electric Operating Manual. (User Instructions)

Lincoln Electric Operating Manual. (User Instructions)
W000011139 Lincoln Weldline 35C50 300 Amp MMA Kit, includes Electrode Holder & Earth Clamp 4m

Lincoln Weldline 35C50 300 Amp MMA Kit, includes Electrode Holder & Earth Clamp 4m

WARRANTYL3 Lincoln Electric 3 Year Parts & Labour Manufacturers Warranty.

Lincoln Electric 3 Year Parts & Labour Manufacturers Warranty.

Related Items

415v Arc Welders FAQs

Straight answers to the questions people ask most when choosing and using a three phase arc welder.

Why choose a three phase 415 volt arc welder?icon-minus-redicon-plus-red

Three phase power supplies energy more evenly and in larger amounts than a single phase supply, so three phase welders can produce higher currents and sustain them for longer. They suit heavy fabrication, structural work, workshops with frequent welding and any job using large electrodes.

They also tend to draw less current per phase for a given output, which puts less strain on the supply.

How do I check my three phase supply is suitable?icon-minus-redicon-plus-red

Look at the welder's input current and recommended fuse or breaker rating on the data plate, then check that your supply, cable and protection can provide it. Your electrician can confirm the spare capacity of the supply and the correct plug or isolator.

A supply that is too weak causes voltage dips, nuisance tripping and an unstable arc, and cable that is too small can overheat. Do not change the rating of protective devices to get around a problem.

What is the difference between 400 volt and 415 volt on a welder?icon-minus-redicon-plus-red

In the UK, three phase supplies are commonly described as either 400 or 415 volts, which is essentially the same nominal supply described in different ways. Welders are designed to tolerate the normal variation in supply voltage.

What matters more is that the machine is designed for the supply voltage range you have. Check the data plate, and if the machine lists a range or multiple voltages, follow the maker's instructions for configuring it.

Is a three phase welder better for thick material?icon-minus-redicon-plus-red

Generally yes. Higher usable current and a stronger duty cycle mean three phase machines cope better with thick plate, large electrodes and long welding runs without overheating.

That said, a lot depends on the individual machine. Compare the output current and duty cycle at the settings you will use, rather than assuming any three phase machine will suit every heavy job.

See all 6 questions for this category
