Rapid Ref : MASTERMIG-205-AC

Kemppi Master M 205 Pulse MIG Welder Air Cooled Package. Dual Voltage 110/230v, 1ph
MASTERMIG-205-AC

Name: Kemppi Master M 205 Pulse MIG Welder Air Cooled Package. Dual Voltage 110/230v, 1ph
SKU: MASTERMIG-205-AC

Select Option

Prices From £2813.00 ex VAT

Shop Parts

The Master M 205 sets new standards for power and performance in a compact MIG welding machine. With a lightweight, easy-to-carry design, you'll get a versatile welder you can take anywhere the job takes you. If you're working in tight spaces, the 7" LCD screen is bright and easy to read, while self-charging LED lights can be switched on to improve safety. The LED lights work with or without mains power.

The Master M 205 is also easy to use. Featuring Weld Assist, it offers automatic parameter settings that help you start welding quickly. It's a straightforward solution that welders of all experience levels can use effectively. Select the material thickness, joint type and welding position, then start welding.

Delivering 200 amps at a 40% duty cycle, the Master M 205 is a pulse MIG welder built for demanding applications. Pulse welding lets you work with a wider range of materials and deliver high-quality results anywhere, thanks to a single-phase power supply. Save time and enhance productivity with 37 built-in MIG/MAG welding programs for Fe, Ss, AlMg5, AlSi5, CuSi3 and CuAl8 filler materials. The Master M 205 includes 17 pulse MIG programs and 20 1-MIG programs.

If you're looking for a compact, easy-to-transport MIG welder that produces high-quality welds in challenging environments, the Master M 205 deserves a spot at the top of your shortlist.

Product Details

Brochures & Manuals

BROCHURES & MANUALS

View Brochure

Kemppi MasterMig 205 / 323 Operating Manual

Kemppi MasterMig Declaration Of Conformity

110v MIG Welders FAQs

Straight answers to the questions people ask most when choosing and using a MIG welder that runs on a 110v supply.

What does dual-voltage mean, and does the machine perform the same on both?

A dual-voltage machine can run from either a reduced-voltage or a standard mains supply. It detects or is set for the supply, and the maximum output is normally lower on the reduced voltage.

That means the same machine may weld thicker material on the higher supply. Check the maker's ratings for each voltage so you know what to expect.

Do I need a special supply or transformer to run it?

On site you normally use a 110v supply from a site transformer or a generator that is set up to provide it. The machine's plug and cable must suit the supply, and the transformer or generator must have enough capacity for the welder's input current.

Check the machine's input rating against the supply, and use cables of the correct rating and length. A weak supply or long thin cable can cause poor performance.

Can I run a 110v welder from a generator?

It depends on both machines, so check the welder's manual and data plate for its input current or power rating, and the generator's manual for its continuous output and whether it has a suitable 110v outlet.

The generator needs enough continuous output for the welder's input demand with some margin, and some welders draw a surge when the arc strikes. Generator and welder makers may state which pairings suit, so follow their guidance. An undersized generator can cause tripping or an unstable arc, and may be damaged. If in doubt, ask a competent electrician.

What wire and gas can I use?

Most of these machines can use the usual solid steel wire with a shielding gas, or a flux-cored wire without gas for outdoor or windy conditions. Some can also weld stainless steel or aluminium with the right wire, gas and setup, but check the manual.

Use the wire size the machine is designed for, since the lower power suits finer wire more than heavy wire.

See all 6 questions for this category
