Pack of 10 (Part Number: 220065) 100A Hypertherm Shields.
Straight answers to the questions people ask when buying plasma torch consumables in multi-packs.
Use the consumable chart in your torch or power source manual. It lists the part for each cutting current and application, such as handheld drag cutting, gouging or mechanised cutting. Match the part numbers to those shown for your torch, and make sure the part is rated for the current you cut at.Parts for one torch family generally do not fit another, even if they look similar. If you are unsure which part you need, check the data plate and manual, or ask our team.
Watch the cut. A sudden or marked decline, such as more dross, a slanted edge or hard starting, is the cue to inspect the parts. Replace a nozzle that has gouges or an orifice that is no longer round. Replace an electrode when the pit in its centre has reached the maker's depth limit, which varies with the current rating, so use the figure in your torch manual.Do not run parts until they fail, as a worn electrode can damage the nozzle and the workpiece.
Yes, this is the usual advice. They wear together, and mismatched old and new parts tend to cut inconsistently. Maker guidance and trade guides say that when the electrode shows wear that needs replacing, the nozzle should be replaced with it.Packs of the individual parts make this easy to do every time. Look at the shield and swirl ring when you change them. A shield can often be cleaned of spatter and reused, and should be replaced if it is physically damaged.
Wipe parts with a clean, lint-free cloth and use clean air to clear debris, especially from the retaining cap. If you wash parts, use clean tap water; never use water from a cutting table.Some O-rings need a thin film of the lubricant the maker specifies, applied only if they look dry. Wipe off any excess, as too much can block gas flow. Fit parts in the correct order, tighten the electrode as the manual describes, and never refit worn parts.
