Rapid Ref : 0700102010

ESAB Swarm A20 Auto Darkening Welding Helmet, Shades 9 - 13 (Adjustable) With Grind Mode
0700102010

£55.02  EX VAT
SSP Suggested Selling Price = £76.11  YOU SAVE £21.09
 Buy in 3 easy interest free payments of £18.34† with
Shop Parts

The lightweight SWARM A20 welding helmet is a heavyweight regarding performance and flexibility. Using an advanced auto-darkening filter (ADF), SWARM A20’s externally selectable shade range from 9–13 tackles the most demanding welding applications. A handy grind setting, also found on the external knob, allows quick attention to finishing work. Further delay and sensitivity settings adjustments can be made easily with dials inside the helmet.

With a streamlined shell design, 1/1/1/2 CE optical clarity, and a replaceable, long-lasting battery – SWARM A20 is the perfect solution for welders looking to improve weld quality.

Features

  • ADF viewing area: 93 x 43mm (3.6 x 1.7")
  • Shade range: DIN 9–13 (adjustable)
  • Grind Mode
  • CE Optical class: 1/1/1/2
  • Arc sensors: 2
  • Fully adjustable delay and sensitivity settings
  • Replaceable 1 x CR2032 battery
  • Low battery indicator LED
  • ADF test button

Product Details

Specifications

Viewing Area: 93 x 43mm (3.6 x 1.7”)

Active Lens Shade (adjustable): 9 – 13

Passive Lens Shade: 4

Power Supply: 1 x CR2032 battery, replaceable

Arc Sensors: 2

Switch Time (Light to Dark): 0.1ms

CE Optical Classification: 1/1/1/2

Standards & Certifications: CE: EN175; EN379; EN166 / ANSI: Z87.1 / CSA: Z94.3 / Brazil CA

Weight: 520g (1.1lbs)

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   ESAB Swarm A20 User Manual

Related Items

ESAB Welding Helmets FAQs

Practical answers on choosing, using and looking after welding and weld-and-grind helmets, including flip-up and air-ready styles.

How often should I replace the cover lens on my helmet?icon-minus-redicon-plus-red

There is no single interval. Replace the clear outer cover lens whenever it is cracked, deeply scratched, pitted by spatter or too dirty to clean with a soft cloth. A damaged cover lens makes the arc harder to see and, on an auto-darkening helmet, can interfere with the sensors.

Cover lenses are normally specific to the helmet, so check the manual or markings for the correct part. Replacing a cover lens is far less involved than replacing the filter itself, so it is worth checking it regularly and changing it early.

What is arc eye and what should I do if I think I have it?icon-minus-redicon-plus-red

Arc eye is an injury to the front surface of the eye caused by the ultraviolet radiation from welding. The eye usually becomes painful and red a few hours after exposure, and it often feels gritty. Most cases are temporary, but other parts of the eye can also be damaged by welding radiation.

The usual cause is striking an arc before the helmet is in place, or being exposed to someone else's arc. If you suspect arc eye, stop work and get medical advice. Always lower the helmet or check the filter is dark before you strike the arc.

What is a weld and grind flip-up helmet, and when is it useful?icon-minus-redicon-plus-red

A weld and grind helmet has a hinged front that carries the welding filter. With the front down you weld; with it lifted you see through a clear inner visor, which is useful for grinding, chipping slag and setting up between welds without taking the helmet off.

This suits fabrication and repair work where you switch often between welding and preparation. Because the front is a moving part, check the hinge is smooth and holds its position, and that the clear visor is undamaged. Following the maker's instructions on which part protects you in each mode is important.

What do the standard numbers and impact letters on a helmet mean?icon-minus-redicon-plus-red

Welding eye and face protection is made to British and European standards covering the frame, the filter and impact resistance. The markings on the helmet and filter usually show the standards it meets, the shade or shade range, an optical quality class and an impact letter, which indicates how much impact the part was tested to withstand.

A letter followed by T means the rating also applies at temperature extremes. The meanings are set out in the helmet manual, which is the authority for your helmet. If markings are missing or illegible, do not rely on the helmet.

See all 6 questions for this category
