Filters, seals, hoses and spares for one maker's powered air welding helmets: what each type of part does and how to choose and look after it.
Powered helmets and hoods with a loose-fitting head top are covered by the European standard EN 12941. It sets performance classes TH1, TH2 and TH3, with a higher number meaning better filtering and less leakage into the head top. Each class can be used with particle, gas or combined filters.When choosing a replacement filter or other part, match it to the class and combination named in the maker's manual and on the data plate. The protection depends on the whole assembly of helmet, hose, blower unit and filter, so do not mix and match without the maker's approval.
The HSE says RPE should be stored according to the manufacturer's instructions, and that leaving it in dirty areas can contaminate the inside and deteriorate it through dirt, solvents and sunlight. HSE guidance adds that cleaning products other than those the maker recommends may cause problems.In practice, clean parts as the manual describes, let them dry and keep them in a clean, dry place away from sunlight, heat and solvents. Keep spare filters in their sealed wrapping until needed.
The HSE says RPE should be inspected thoroughly before each use and that, for reusable RPE, you should keep a record of regular examinations, maintenance, repairs and, where appropriate, testing. Checks usually include the seals, hose, helmet shell, filters, battery and airflow.What counts as an adequate schedule depends on the equipment and the maker's instructions. HSE guidance explains who should carry out maintenance: trained, competent people. Report anything damaged and take it out of use until it is put right.
No. HSE guidance says FFP3 disposable masks and P3 particle filters do not protect against welding gases, and the same applies to a particle filter on a powered unit. Gas and combination filters exist, and powered units can be used with particle, gas or combined filters, depending on the unit.If your work produces gases or vapours as well as fume, check the risk assessment and the maker's manual to see which filter is required, and fit only the type named for your unit.
