    ESAB Renegade ES 210i Ready To Weld Package with 3m MMA Cable Set - 115 / 230v, 1ph
    0447700881

    £760.00  EX VAT
    SSP Suggested Selling Price = £1085.04  YOU SAVE £325.04
     Buy in 3 easy interest free payments of £253.33† with
    Additional items to consider

    Ultimate durability in portable edition

    The Renegade ES is a professional single-phase, MMA and Live TIG welding machine with the most resistant IP23 housing designed for use in demanding environments.

    The Renegade ES is equipped with a high-quality carry strap with multiple lift points, ready to move with you when portability is required. A built-in active PFC circuit also provides an uninterrupted power supply, even with long extension cables (up to 100m).

    The Renegade ES has been designed to weld with any type of electrode in superior quality, including 6010 cellulosic. Users have direct access to parameters and memory buttons, which makes the machine very easy to work with.

    Package includes 3m work lead, 3m electrode holder and shoulder strap.

    Features

    • Highest durability housing with IP23 for indoor and outdoor use
    • For professional MMA welding with electrodes up to 4mm with a high output power
    • PFC for stable arc even with extra-long mains cable, up to 100m
    • A powerful voltage booster provides additional arc voltage for superior cellulosic weld performance
    • Easy to read and quick to set panel, increasing the accuracy and reducing the downtime
    • Adjustable Hot Start and Arc Force for optimal arc adjustment
    • Three memory settings for easy access to welding parameters
    • ESAB Handy 200 electrode holder included

    Product Details

    Specifications

    • Mains Voltage: 115/230 VAC ±15%, 1ph, 50/60 Hz
    • Fuse Slow: 16 A
    • Rated KVA: 3.3 KVA (115VAC), 6 KVA (230VAC)
    • Energy save mode: <30 W
    • Welding Output MMA 115 VAC: 110A / 24.4V at 25%, 71A / 22.8V at 60%, 55A / 22.2V at 100%
    • Welding Output MMA 230 VAC: 180A / 27.2V at 25%, 116A / 24.6V at 60%, 90A / 23.6V at 100%
    • Welding Output TIG 115 VAC: 140A / 15.6V at 25%, 90A / 13.6V at 60%, 80A / 12.8V at 100%
    • Welding Output TIG 230 VAC: 210A / 18.4V at 25%, 135A / 15.4V at 60%, 105A / 14.2V at 100%
    • Setting Range MMA 115 VAC: 15A / 20.6V –110A / 24.4V, 230 VAC MMA: 15A / 20.6V –180A / 28.4V
    • Setting Range TIG 115 VAC TIG: 10A / 10.4V –140A / 15.6V
    • Setting Range TIG 230 VAC TIG: 10A / 10.4V –210A / 18.4V
    • Power Factor Max Current: 99%
    • Open Circuit VDC High: 78 VDC
    • Enclosure class: IP23
    • Operating Temperature: -10 to +40°C (+14 to +104°F)
    • Dimensions: 460 x 200 x 320mm
    • Supply plug: CEE 16 A
    • Weight: 9.9Kg

    Brochures & Manuals

    Related Items

    110v Arc Welders FAQs

    Straight answers to the questions people ask most when choosing and using a 110 volt arc welder.

    Why are 110 volt arc welders used on sites?icon-minus-redicon-plus-red

    On many construction and industrial sites, portable electrical equipment is required to run from a reduced 110 volt supply, because it lowers the risk of a serious shock if a cable or tool is damaged. A welder that runs from 110 volts can be connected to the site supply or to a suitable generator.

    Check your site rules, because requirements vary, and follow the instructions of the person in charge of site electrical safety.

    What size electrodes can I use on a 110 volt welder?icon-minus-redicon-plus-red

    This depends on the machine's output when run on 110 volts. Smaller electrodes need less current and suit these welders best, and thicker electrodes need more current than a 110 volt machine may be able to provide.

    Check the maker's guidance for the electrode sizes the machine can run at its 110 volt output. If you try to use an electrode that needs more current than the machine can supply, the arc becomes weak, difficult to strike and prone to sticking.

    What supply and plug does a 110 volt arc welder need?icon-minus-redicon-plus-red

    Site 110 volt equipment normally uses a yellow industrial plug and socket, usually at a particular current rating. The supply must be able to provide the current the welder draws, and the plug and cable must be rated for it.

    A welder drawing more current than the supply or plug is rated for will trip protective devices or overheat the cable. Check the current draw on the welder's data plate and make sure the supply, transformer or generator can provide it.

    Can I run a 110 volt welder from a site transformer or generator?icon-minus-redicon-plus-red

    Often yes, but the transformer or generator must be big enough for the current the welder draws, with enough capacity left for other equipment connected at the same time. An undersized supply makes the arc unstable and can cause cut-outs.

    For generators, check the output rating covers the welder's input requirement, and ask whether the generator suits inverter equipment. Follow the generator and welder manufacturers' guidance and any site rules.
